Simple Clamp Base

Benefits

• All-in-one kit contains the original Simple Clamp Base, aluminum backing plate and 4mm x 0.7 - 10mm* stainless steel button cap fasteners.
• Metal clamps for strength and durability - will not deform like plastic.
• Perfect for a growing army of designers, integrator and people looking to create their own installation and connect a 67 Designs Ball2Ball™ arm or any other base or holder component with a 20mm ball.

Product Details

• This utilizes 3 x 4mm threaded screws on a 20mm diameter. The outer diameter is 32mm.
• Ball2Ball™ Arms and other components sold separately. In images for example only. Do not forget to add them to your cart!
• Registered design.

Design Specifications for Installation

• The 4mm threaded holes will accept a thread of not more than 4mm depth. Design you mating parts to work with the appropriate 4mm fastener of your choosing.
• The 4mm threaded holes are spread out 120 degrees apart on a 20mm diameter. The design prevents the base from turning in this configuration.
• The base is 32mm in diameter.
• Patented - US12115919

* If your specific installation requires different thread length to suit your design or situation, you will need to be purchase those from a local hardware store.
